:MsHelp

Seems that quite a lot of people have already experienced some kind of error with the CRM Outlook client. Today was one of those days again where I experienced an error. I did a clean install of the CRM 2011 Outlook client and connected to the CRM 2011 on premises environment. All seemed to be going extremely well. My contacts were being synchronized etc…

I wanted to track an email in CRM so I clicked the button “Track”. First a little pause and then boom, an error box popped up saying “An unknown error occurred while synchronizing data to Outlook.”.

Ok not much to go with so I checked if there were any logs in the log directory: (“c:\Users\[USERNAME]\AppData\Local\Microsoft\MSCRM”)

No results there so I had to find a different solution to get some more information. I enabled tracing in Diagnostics tool that comes with the CRM 2011 Outlook client.

Tried to track the email again to get that error box again and looked in the tracing file. (C:\Users\[USERNAME]\AppData\Local\Microsoft\MSCRM\Traces)

Now I did find something:

[2012-04-06 11:08:08.6] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CMailItemHelper::HrRetrieveAndSetRegardingIdInOutlook File: c:\bt\32691\src\application\outlook\addin\emailhelper.cpp Line: 999
>hr = 0×80004004
[2012-04-06 11:08:08.7] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CMailItemHelper::HrPromoteMailItemInCrm File: c:\bt\32691\src\application\outlook\addin\emailhelper.cpp Line: 1754
>hr = 0×80004004
[2012-04-06 11:08:08.7] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CMailItemHelper::HrCreateInCrm File: c:\bt\32691\src\application\outlook\addin\emailhelper.cpp Line: 1406
>hr = 0×80004004
[2012-04-06 11:08:08.7] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CMailItemHelper::HrCreateInCrm File: c:\bt\32691\src\application\outlook\addin\emailhelper.cpp Line: 1432
>hr = 0×80004004
[2012-04-06 11:08:08.94] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CMailItemHelper::HrCreateInCrm File: c:\bt\32691\src\application\outlook\addin\emailhelper.cpp Line: 1452
>hr = 0×80004004
[2012-04-06 11:08:08.94] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CMailItemHelper::HrCreateInCrm File: c:\bt\32691\src\application\outlook\addin\emailhelper.cpp Line: 1454
>hr = 0×80004004
[2012-04-06 11:08:08.95] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CMailItemHelper::HrPromoteItemToCrm File: c:\bt\32691\src\application\outlook\addin\emailhelper.cpp Line: 243
>hr = 0×80004004
[2012-04-06 11:08:08.95] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CItemHelper<struct Outlook::_MailItem>::PromoteItemToCrm File: c:\bt\32691\src\application\outlook\addin\ItemHelper.h Line: 354
>hr = 0×80004004
[2012-04-06 11:08:08.95] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CSyncToOutlook::SyncItemByTypeByAction File: c:\bt\32691\src\application\outlook\addin\synctooutlook.cpp Line: 1451
>hr = 0×80004004
[2012-04-06 11:08:08.96] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CSyncToOutlook::ProcessSyncResult File: c:\bt\32691\src\application\outlook\addin\synctooutlook.cpp Line: 1784
>hr = 0×80004004
[2012-04-06 11:08:08.97] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | CSyncToOutlook::ProcessSyncResult File: c:\bt\32691\src\application\outlook\addin\synctooutlook.cpp Line: 1831
>hr = 0×80004004
[2012-04-06 11:08:08.97] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | HrGetErrorDescription File: c:\bt\32691\src\application\outlook\addin\..\common\ResourceManagerEx.h Line: 148
>hr = 0×80004005
[2012-04-06 11:08:08.99] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | HrLoadManagedString File: c:\bt\32691\src\application\outlook\addin\..\common\ResourceManagerEx.h Line: 35
>hr = 0×80040203
[2012-04-06 11:08:08.99] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | LoadManagedString failed with hr = 0×80040203. Function: HrLoadManagedString File: c:\bt\32691\src\application\outlook\addin\..\common\ResourceManagerEx.h Line: 37
[2012-04-06 11:08:08.100] Process:OUTLOOK |Thread:5696 |Category: Unmanaged.Platform |User: PlatformUser |Level: Error | HrGetErrorDescription File: c:\bt\32691\src\application\outlook\addin\..\common\ResourceManagerEx.h Line: 154
>hr = 0×80040203

I’m just posing that long error message so that others with the same error will hopefully have something with this post.

So how did I fix this problem?

I though I was stuck because on the forums there wasn’t much information about this issue. Here’s what I did:

1) Go into control panel
2) Open Programs and Features
3) Select “Microsoft Dynamics CRM 2011 for Microsoft Outlook”
4) Click Uninstall/Change
5) Select Repair

Hope this helps for you too!

No Comments

Today I wanted to create a custom workflow activity in code. I had some issues while creating and building this project in Visual Studio.By trial and error I slowly discovered what I was doing wrong. So here is you and for myself as future reference the setup of a CRM 2011 custom workflow activity.

1) Add XRM binaries from CRM 2011 SDK BIN folder. You need to add the following two:
- microsoft.xrm.sdk
- microsoft.xrm.sdk.workflow

2) These two assemblies have dependencies on System.ServiceModel and System.ServiceModel.Web so you need to add these too.
If you can’t add them, make sure that the target framework in you project properties is set to “.NET Framework 4″ and not “.NET Framework 4 Client Profile”

If you don’t add them then you’ll get build errors like:

- The referenced assembly “microsoft.xrm.sdk” could not be resolved because it has a dependency on “System.ServiceModel.Web, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35″ which is not in the currently targeted framework “.NETFramework,Version=v4.0,Profile=Client”. Please remove references to assemblies not in the targeted framework or consider retargeting your project.
- The referenced assembly “microsoft.xrm.sdk.workflow” could not be resolved because it has a dependency on “System.ServiceModel.Web, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35″ which is not in the currently targeted framework “.NETFramework,Version=v4.0,Profile=Client”. Please remove references to assemblies not in the targeted framework or consider retargeting your project.

3) Also add a reference to System.Runtime.Serialization if you are going to use an entities class generated by crmsvcutil.exe

Now you are finally set to start coding your custom CRM 2011 Workflow Activity Library…

4) Remove Activity1.xaml

3) Add a new C# class file to contain your custom workflow code

Once the workflow activity library is created…

5) Make sure to sign your assembly via the Project Properties / Signing tab

Custom workflow activity libraries need to be registered like a regular CRM plugin so…

6) Make sure you are a CRM 2011 deployment administrator otherwise you’ll not be able to register the plugin

Use the custom workflow activity in your CRM 2011 processes.

No Comments

Interesting blog posts

History of Microsoft Dynamics CRM Online

Microsoft CRM 2011 How to Configure IFD Hosted Setup

Using FetchXML Aggregation to Create a Rollup Plugin in Microsoft Dynamics CRM 2011

Now You Can Handle “Nearly Static” Data with Microsoft Dynamics CRM 2011

CRM 2011 Outlook Client Configuration – XML Configuration File Tip

Invalid characters – Migrating Salesforce Full Export data file to CRM

CRM 2011 – Things to consider when building a Microsoft CRM 2011 VM

CRM 2011 – Access hidden mappings via SQL or REST

How can I get information out of Dynamics CRM?

MSCRM 2011 Developer Toolkit Walkthrough

Too cool! Triggering CRM workflow based on survey responses

Demystifying Dynamics CRM Online

Adding Microsoft Dynamics CRM Entity Folders to Favorites Area in Outlook

Adding a custom tab with multiple groups to the CRM 2011 Ribbon

Can your CRM solution do this with Outlook?

About escalated menus and Lookups.

Building Business Processes in Dynamics CRM 2011: Installment 6

CRM Online as cloud based BPM application

Available now! Extending Microsoft Dynamics CRM 2011 training

Update rollup 3 released for Dynamics CRM 2011

Podcast and Overview: Microsoft Dynamics CRM 2011 Update Rollup 3

CRM SDK 5.0.5 Released

CRM Migration Assistant 1.2 Released

MSCRM 2011 Developer Toolkit Walkthrough

Screencasts

Microsoft Dynamics CRM 2011 Series – Add Marketing Capabilities by Zero2Ten

Microsoft Dynamics CRM 2011 – Account Management with Custom Activities

Handy tools

View Replicator for CRM2011

No Comments

I read some really great news a couple of days ago concerning the announcements made at WPC 2011. Microsoft Dynamics CRM currently has more than 30000 customers and more than 2 million users worldwide. For me it wasn’t such a big surprise though..Dynamics CRM really is a great product to work with. It’s easy to use, it has a great ROI and a low TCO. What more do you want from a CRM system?

Dynamics CRM is not slacking when it comes to new technology. We already have CRM Online, which is basically Dynamics CRM in the cloud. This provides Small to mid size businesses to benefit from Dynamics CRM with reduced upfront costs. To top this, Microsoft will soon be pushing CRM Online to the Office 365 package. Next to SharePoint Online, Exchange Online, Lync Online and the Office applications this great cloud based software suite will also offer Dynamics CRM Online. With this you’ll have an all in one package for your business. What’s great about Office 365 is that it’s cloud based. You don’t have to manage the software yourself, they are accessible from anywhere where you have an internet connection, they integrate so well with each other and for small to mid sized companies the price tag is very interesting. You may be wondering..when will we be able to enjoy Dynamics CRM in the Office 365 package? Well, Microsoft promised to release these updates by the end of 2011.  If you haven’t heard of Office 365, but would like to know more, then check out this page: http://www.microsoft.com/office365/

Coming back to these updates, we can expect for Dynamics CRM in Q4 of 2011. Here are some key points to remember:
- Identify federation to support single sign-on to improve the experience for end users
- Improved disaster recovery with in-region replication to further protect data and offer higher levels of business continuity in the event of a disaster.
Microsoft is also investing to improve the social aspects of Dynamics CRM:
- Micro-blogging: Status updates and notifications regarding business events and actions, bringing simple experiences for users similar to Facebook and Twitter.
- Activity feeds: Configurable real-time notifications on all important relationships and significant business events via a blended view of micro-blog posts and all interactions for a person, customer or sales opportunity.
- Conversations: Users will be able to post questions, observations, suggestions and status updates, allowing them to collaborate quickly and efficiently, locate information or expertise and gather feedback from others.
- Automated activity updates: Microsoft Dynamics CRM will be able to post information directly to the Activity Feed based on configurable event rules, e.g. a sales opportunity is closed. Users can subscribe to or “follow” these Activity Feeds, and consume them in a variety of ways.
- Windows Phone 7 mobile application: With a new Windows Phone 7 mobile app, users will be able to view their Activity Feeds, while away from the office.

To close this post, in the first half of 2012, Dynamics CRM will be supported on other browsers than Internet Explorer like for example Safari, FireFox and Chrome. This is great news for Mac users and the people who really like working in non IE browsers.

Looks like Microsoft has some big plans for Dynamics CRM and I’m really looking forward to these updates!

You can watch the keynote which Krill Tatarinov gave at WPC 2011 via the following link: http://digitalwpc.com/Videos/VisionKeynoteVideos/2/KirillTatarinov#fbid=0HAoXcXTXnG

Other resources:

http://redmondmag.com/Articles/2011/07/12/Microsoft-Beefing-Up-Dynamics-CRM-in-Q4.aspx?utm_source=twitterfeed&utm_medium=twitter&Page=2

http://blogs.msdn.com/b/crm/archive/2011/07/13/microsoft-dynamics-crm-at-the-2011-worldwide-partner-conference.aspx

http://preactcrm.blogspot.com/2011/07/microsoft-dynamics-crm-q4-2011-update.html

No Comments

Over the weekend I started working on a new virtual image that I could use for CRM 2011 experimenting. For the OS I chose Windows Server 2008 R2 x64. Once the OS and SQL Server 2008 were installed I launched the Windows updates. Obviously there were a lot of updates that needed to be installed so this took a while. I also chose to install the latest service pack for Windows Server (SP1) and Internet Explorer 9. IE9 is of course supported by Dynamics CRM 2011 (and CRM4 since rollup 13). Once all the preparations were done I could finally start with the installation of Dynamics CRM 2011.

I loaded the .ISO file and there came the splash screen of Dynamics CRM 2011.

Here I clicked on the first option “Install Microsoft Dynamics CRM 2011 Server”. Boom, immediately my click is followed by an error related to splash.exe saying “Microsoft CRM Splash Screen has stopped working”. This is kind of problematic because it’s blocking me from the installation. Of course I could go and look for the different exe files but that would be too much of a hassle. Here is some more information concerning the error:

I had read about this problem before on the Microsoft Dynamics CRM community forums. There I couldn’t present a better solution because at that time I didn’t know exactly what was going on. Now I had the problem myself and I just had to find a better workaround!

Immediately I noticed from the error that something was wrong with “mshtml.dll”. It was clear for me that it had something to do with Internet Explorer 9 which I had just installed. Why exactly I can’t say..but Internet Explorer had to go, temporarily (because I really like IE9 and it works perfectly with Dynamics CRM 2011).

So I went to Control Panel and went looking for “Internet Explorer 9”. It’s not in the default list of installed programs. You need to click on “View installed updates” in the left menu.

Now you will see “Internet Explorer 9” in the list:

Remove this for now and restart the system. Now you will have the previous version of Internet Explorer again.

Now when I run the splash screen again, the install continues like it should be. For me this solves the problem in a decent way. Once the install is done I can just install Internet Explorer 9 again. Of course this is a workaround..I‘ll make sure the bug information is sent to Microsoft.

No Comments

I’m involved in a lot of Dynamics CRM data migration/integration projects. I know how much time it takes to analyse, clean up and import the data into a Dynamics CRM system. If you’ve done this in the past, then you know it can get complicated very quickly. Definitely if you have a lot of relationships.

With this version of Dynamics CRM I was pleased to see that you get some extra help in preparing your data fore the import. With CRM 2011 you can generate templates via the system that will help you with the preparation of your data. These import templates are in an XML format which you can open with Excel.

Generating the import template from an entity view

Generating the templates is done via the CRM 2011 system and it’s very easy. You can generate it per entity or from a more central location. Let’s say I want to retrieve the template for the account entity. I just navigate to the accounts view and click on “Import Data” from the ribbon. In the dropdown list, select “Download Template for Import”.

Generating the Import Template via the settings area

If you want, you can also retrieve the templates via the settings area. To do this click on “Data Management” in the left hand navigation. From this view select “Templates for Data Import”.

This will open a window with a dropdown where you can select an entity from. Once you have made your selection, click on the download button to download the template.

Opening the Import Template

Once this is downloaded, you will notice that it’s an XML file. But no worries, you can open it in Microsoft Excel. At least when you have unblocked the file. This is just a security measure to prevent you from opening unwanted dangerous files. If you don’t unblock the file, you will be get the error message “The file is corrupt and cannot be opened”.

To unblock the file, right click on the XML file and open the properties. Here you will see a button to unblock the file.

Now you should be able to open the template without a problem and you should see something like this:

Inspecting the Data Import Template

This is an extremely handy Excel file to have and it will help you a lot when you are preparing the data. Here is a list of features about the Import template:

• - The required fields are marked in bold.
• - The column headers are the same as the display names of your CRM 2011 fields in your entity. Because of this, CRM 2011 will automatically map your data to the correct fields during the data import.
• - All the fields from your entity are in here, so you don’t  need to open your entity all the time and copy over the fields.
• - If you click on the header you will see the description of the field.
• - Option set fields contain a dropdown so you can easily select your value. No incorrect spelling and all the possible values are right there in Excel.

All that is left to do is to fill in the Import template and import it using CRM 2011.

No Comments

A lot of times I read on forums that people are asking if it is possible to migrate their data and customizations from CRM2011 online to CRM2011 on premises. Customizations is not really a problem because you can just import and export the solution. However, migrating data is not so straightforward.

Many companies first start with the CRM2011 Online and then later migrate to CRM2011 on premises. Why do they do this? Here are some possible reasons:
- Because CRM2011 Online might have technical limitations for their specific needs  (not that there are so many differences)
- They didn’t want to pay for server licenses and CALs in the beginning because they were just "trying out" CRM2011.
Now after some time they see what a great product Dynamics CRM is and want to invest in implementing it in their own environment.
- They don’t like the idea of having their company data in the cloud and not in their own environment. (I think we can trust Microsoft
with our data, but you would be surprised how many companies think like this)
- Legal issues: In the past I was working with a customer that wanted to change certain clauses in the contract, because they didn’t agree with certain points. From experience I’ve learned that Microsoft rarely or never changes its contract.

I’m not saying these are all valid reasons to switch. There are also many benefits of choosing for CRM2011 Online, think of scalability for instance.

But if we come back to the question: Is it possible to migrate data and customizations from CRM2011 online to CRM2011 on premises?
Yes it is, no problem! To support this procedure Microsoft has released a handy whitepaper that will guide you step by step through the process
of migrating your online CRM2011 organization to CRM2011 on premises.

You can download the whitepaper via the following link: Microsoft CRM Online Data Migration to Microsoft Dynamics CRM 2011 on-premises

Another solution is to use a third party data migration application like Scribe. Using this application you can connect to your online environment and your on premises environment to copy over the data.

No Comments

In the past when I was mainly working on custom software development projects, I liked to wireframe my application before actually diving into the code or IDE. To create these mockups I used tools like Balsamiq.

Creating mockups can save you a lot of time. Definitely when you need to start from the ground up. You don’t have to worry too much about functionality or the esthetical part of the application. The client will not start complaining that he/she doesn’t like that certain tone of grey that you have used or that a certain button doesn’t behave exactly like it should.

With Dynamics CRM this is of course a different story. First of all, you get already the base functionality straight of the box. Second, there will probably not be a lot of discussion possible concerning the GUI  of the application itself. Normally you stick to what you get out of the box.

However I see some added value in wire framing, prototyping or sketching your CRM2011 application. I will come back to that later on.

I went looking for some decent approach to start prototyping Dynamics CRM applications and my search brought me to mSketch from Magnetism. mSketch is a collection of stencils that can be used to create mockups of CRM2011 applications. All the work is done with Expression Blend 4 SketchFlow. If you don’t have that much experience with this tool, I would really advice you to check it out. This great tool was introduced by Microsoft to shorten the bridge between developer and designer creating WPF or Silverlight applications. The company Magnetism was also no stranger to me because I had been following their blog posts and work on Twitter for a while.

With mSketch you get a solution that you can open with Expression Blend. This solution contains the CRM2011 forms predefined by Magnetism. These forms you can then use to create your own implementation. A nice to have would be to have an installer that would install the stencils as a project type in Expression Blend.

I was quite impressed by the level of detail that the team from Magnetism had put in the creation of these stencils. The ribbon, the tabs, the fields.. a really nice job in total. Magnetism also provided a decent user guide that you can use working with the mSketch stencils. This is always on my checklist when I try new tools or applications: Is there a decent user guide that will actually help me? Yes there is with mSketch, check it out here: http://help.magnetism.co.nz/#getting-started-with-msketch

Here is what the stencils look like inside Expression Blend:

Ok, so the stencils gave me a great head start. All I had to do now was to copy one of the forms in my own solution and start the customization of my custom CRM2011 application. Using sketchflow functionality you can define the paths that your application needs to follow. Once completed I just had to push F5 and I had a running prototype of my custom CRM2011 application.

Now to come back to a previous discussion, what are the benefits of prototyping your CRM2011 application? Here are some of the benefits I see with prototyping a CRM2011 applications.

1) You can use Expression Blend 4 and the mSketch stencils together with a client to rapidly workout a draft of their CRM2011 application.

2) The client can easily play around with the mockup using the sketchFlow preview created by Expression Blend. This can be deployed to IIS.

3) You don’t need to have CRM2011 installed from the beginning, everything is done in Expression Blend (or IIS for the testing). In cost and performance requirements this makes a big difference.

4) You can limit the discussions concerning the placement of fields, the ribbon, the operations or scripts on a form. You can explain that this is just a draft, a prototype. The full functionality will come later.

More information on the Magnetism mSketch stencils: http://www.magnetism.co.nz/solutionscasestudies/solutions/msketch.aspx
mSketch user guide: http://help.magnetism.co.nz/#getting-started-with-msketch
More information on Expression Blend 4 + SketchFlow: http://www.microsoft.com/expression/products/blend_overview.aspx

No Comments

In this short blog post I would like to discuss the different methods to import your Outlook contacts into Dynamics CRM2011.

Track Outlook contacts

Tracking a contact in CRM 2011 means that you will select your individual contacts and select “Track in CRM” from the context menu. If this operation is completed you will have the same contact created in Dynamics CRM. The benefits are that your contacts are automatically kept in sync. For instance when you change a property of that contact in CRM, this property will be synchronized with the contact in Outlook. If you delete the contact in Dynamics CRM, it will stay available in Outlook. If you delete the contact in Outlook, it will stay in Dynamics CRM.

Steps:

1) Select you contact (one or multiple)

2) Right click and select “Track in CRM”

Bulk import

If you want to be able to manage all your contacts in Dynamics CRM, then you can use the “Add contacts” wizard available in the Outlook client. This is a convenient way of moving all your contacts to Dynamics CRM2011. I would advice to set up decent duplicate detection rules to prevent duplicate records.

Steps:

1) In Outlook, go to “File” and click on “CRM”

2) Click on “Import Contacts” and select “Add Contacts”

3) Now the “Add Contacts” wizard will open

4) Now the wizard will analyze your data

5) Once the analysis is done, the wizard will show you a list of what is has found. Here you can choose to group your contacts per

- Account (Accounts will be created based on the companies linked to your contacts)

- Email domain

- Category (Category specified in Outlook)

Here you can also configure whether or not an account should be created for the companies linked to the contact. Another nice feature is that you can decide here whether or not future communication with these contacts should be synchronized to Dynamics CRM.

6) Finally you can click on the “Add Contacts” button to add your contacts to Dynamics CRM2011.

No Comments

I was trying to view a specific record in an entity set when my Internet Explorer showed the message “Internet Explorer cannot display this feed”.

It seems that this has something to do with the build in RSS feed reader in IE. If you want to view the raw XML returned from your REST query without this error, then you need to disable this RSS feed reader. The steps to do this are the following:

1) Go to Tools –> Internet Options

2) Click on the “Content” tab

3) Under the section “Feeds and Web slices”, click “Settings”

4) Uncheck “Turn on feed reading view”

5) Click “Ok” and again “Ok”

Now when I try to view the details of a specific account using the following link:
xrmservices/2011/organizationdata.svc/AccountSet(guid’A76567FA-DF4E-E011-9FE0-951FA97376B7′)

I will see something like this

No Comments
